RESIDENTIAL ELEVATOR PVE30
Click Image for Gallery
Single-Passenger Residential Elevator
The PVE30 is the smallest residential elevator in the world, yet it is just as capable as other residential elevators that are much larger and much more expensive. The PVE30 elevator has a 350lb (159kg) lift capacity and is capable of up to 50 ft. (15m) of rise over as many as five stops. With a 30 inch outside diameter, it is small enough to fit in even the most modest-sized home. If you thought a home elevator was out of reach for you because of size constraints, this is the solution you have been looking for.
Standard Features
- No pit, hoist way, or machine room required
- 50 ft (15m) Total Rise Max
- 30 ft/min travelling speed
- Two to Five Stops
- External cylinder diameter: 750mm (30 inches)
- Internal cabin diameter: 521mm (20 ½ inches)
- Internal cabin height: 2005mm (79 inches/ 6’7”)
- Entrance way opening: 521mm (20 ½ inches)
- Through Floor or Balcony Mount Landings
- Power Supply: 25 AMP 220VAC
- In-line door openings
- Aluminum and polycarbonate cylinder structure
- Automatic interior LED lighting and fan
- Mechanical emergency safety brake system
- 5 years limited manufacturer warranty
- ASME A17.7 Certified
